Eric Reinholdt RA NCARB – REVIT template

Description

Eric Reinholdt, RA, NCARB – REVIT Template – Schematic

You’ll get:

Graphically compelling visuals right out of the box without fussing or experimenting

View templates, line styles + weights, filled regions, detail components, room/wall/door/window tags, section, elevation markers and more. Everything you need to effectively communicate with clients, consultants and contractors

A small sample floor plan + elevation for reference

A minimalist, well-designed Arch D titleblock family

Done for you settings you can rely on to output graphically strong drawings immediately

Custom shortcuts to save you time.

Imagine starting a new drawing knowing all your favorite families, notations and settings are in one place and ready to use. Using a template file ensures every drawing begins with the correct settings and standards each time, all with one click.

The included files will help you to replicate the simple, graphic style Eric Reinholdt uses for all his digital presentations in his studio, 30X40 Design Workshop.

BONUS: Solar Path Diagram Detail Component (modify per your site location + latitude)
